Page 211 - Catalog

www.bigwsales.com

Diaphragm Pumps

PART DESCRIPTION MAX MAX PORT SIZE MAX
NUMBER GPM PSI DRAW
8000 SERIES BYPASS PUMPS 12 VDC
8000-543- Standard Bypass Pump: Viton® valves, 1.8 50 5.5
Santoprene® diaphragm, 45 PSI internal
250 bypass

8000-543- Standard Bypass Pump: Viton® valves, 1.3 40 5.5
Santoprene® diaphragm, 35 PSI internal
210 bypass 3⁄8" NPT
Female
8000-543- Standard Bypass Pump: Viton® valves, 1.5 60 7.1
Santoprene® diaphragm, 60 PSI internal
220 bypass 8000-543-250

8006-543- Bypass Pump with Reversed 1.4 50 5.5
Pumphead:Viton® valves, Santoprene®
250 diaphragm, 45 PSI internal bypass

PART DESCRIPTION MAX MAX PORT SIZE MAX
NUMBER GPM PSI DRAW
8000 SERIES NO CONTROL PUMP 12 VDC PUMPS

8000-543- Front Adapter Pump: Viton® valves, 1.8 100 3⁄8" NPT 8.8
Santoprene® diaphragm, 1⁄4" FNPT
290 adapter mounted on switch ports Female

8000-543-290
PART DESCRIPTION MAX MAX PORT SIZE MAX
NUMBER GPM PSI DRAW
8000 & 8020 SERIES BYPASS PUMPS 115 VAC
8000-533- Bypass Pump: Viton® valves, San-
250 toprene® diaphragm, 45 PSI Internal 1.4 50 3⁄8" NPT 0.54
Bypass
Female
8020-503- Bypass Pump w/Power Cord: Viton® 1.5 40 0.56
valves, Santoprene® diaphragm, 45 PSI
250 Internal Bypass
8000-533-250

PART DESCRIPTION MAX MAX PORT SIZE MAX
NUMBER GPM PSI DRAW
8000 & 8020 SERIES AUTO DEMAND PUMPS 115 VAC

8000-533- Standard Demand Pump: Viton® valves, 1.4 60 0.64
Santoprene® diaphragm, 60 PSI demand
236 switch
8020-513- Standard Demand Pump: Viton® valves, 1.5 60 0.57
Santoprene® diaphragm, 60 PSI demand
236 switch with 6 ft power cord 3⁄8" NPT
Female
8020-833- High Pressure Pump w/6 ft. Power Cord: 1.6 100 0.95
Viton® valves, Santoprene® diaphragm,
238 100 PSI demand switch 8000-833-238
8030-863- High Pressure Pump: Viton® valves, 1.5 150 1
Santoprene® diaphragm, 150 PSI
239 demand switch
