Page 210 - Catalog

Diaphragm Pumps

PART DESCRIPTION MAX MAX PORT MAX
NUMBER GPM PSI SIZE DRAW
5059 SERIES AUTO DEMAND PUMPS 12 VDC
5059-1311-D011 Automatic-Demand Pump: 12-volt, 5.3 60 1/2" npsm* 17.0
sealed motor Santoprene® diaphragm,
5059-1310-D011 Viton® valves, built in pressure switch 5.3 60 1/2" NPTF 17.0
set at 60 PSI.
5059-3611- Bypass Pump: 12-volt, sealed motor 5.3 90 1/2" npsm* 20.9
D011 Santoprene® diaphragm, Viton® valves, 5059-1310-D011
5059-3610- bypass versions are set at 90 psi 5.3 90 1/2" NPTF 20.9
D011 (5.86 bar)

* 1/2" -14 American National Standard Straight Pipe Thread

PUMPS PART DESCRIPTION MAX MAX PORT SIZE MAX

DRAW
NUMBER
PSI
GPM
8000 SERIES AUTO DEMAND PUMPS 12 VDC
8000-343-236 All Viton® Pump: Viton® valves, Viton® 1.2 60 5.8
diaphragm,60 PSI demand switch 3⁄8" NPT
Lawn and Garden Pump: Viton® valves, Female
8000-541-236 Santoprene® diaphragm, 60 PSI demand 1.0 60 3.8
switch
Low Flow Standard Pump: Viton®
8000-542-136 valves, Santoprene® diaphragm, 60 PSI 1.2 60 6.0
demand switch 1⁄2" MSPT 8000-543-236
Male
Standard Pump: Viton® valves, Santo-
8000-543-136 1.8 60 7.3
prene® diaphragm, 60 PSI demand switch
Standard Pump: Viton® valves, Santo-
8000-543-236 1.8 50 6.4
prene® diaphragm, 60 PSI demand switch 3⁄8" NPT
High Pressure Pump: Viton® valves, Female
8000-543-238 Santoprene® diaphragm, 100 PSI demand 1.8 100 8.7
switch
High Pressure Pump: Viton® valves,
8000-543-138 Santoprene® diaphragm, 100 PSI demand 1.8 100 1⁄2" MSPT 8.7
switch Male
Standard Pump w/Wire Harness:Viton®
valves, Santoprene® diaphragm, prewired
8000-543-936 1.8 50 6.4
with two wire molded connectors, 60 PSI
demand switch 3⁄8" NPT 8000-543-936
Transfer Pump: Buna valves, Geolast® Female
8000-643-236 1.8 60 6.8
diaphragm, 60 PSI demand switch
High Pressure Pump: Viton® valves,
8030-813-239 Santoprene® diaphragm, 150 PSI demand 1.6 150 12.0
switch
