Page 208 - Catalog

Diaphragm Pumps & Accessories

MODEL DESCRIPTION MAX MAX
NUMBER GPM PSI
CONTROL UNITS FOR PRESSURE AND OUTPUT CONTROL
OF SPRAYER
9910-KIT1990 Control unit for Model 9910-D252. Includes relief valve 6.0 290
pressure/bypass selector, 5/8" HB bypass port and 3/8"
HB outlet.
9910-GS40GI Control unit for Models 9910-D30 and D50. Includes 21 580 9910-KIT1990
pressure gauge, high pressure relief valve, complete by-
pass lever, two 1/2" HB outlets with individual shut-offs,
and 3/4" HB by-pass.
9910-GR40 Control unit for Models 9910-D303 and D403. Includes 11 580
adjustable high pressure relief valves, complete bypass
lever, 2-1/2" gauge, two 1/2" HB outlets with individual
shut-offs and 5/8" HB bypass.
9910-RM40 Control unit for Model 9910-D503. Includes high 24 580
pressure relief valve, complete by-pass knob, two 1/2"
HB outlets with individual shut-offs and 1” HB by-pass.
Unit can be either direct or remote mounted. 48 725 9910-GS40GI
Remote mounted control unit for Models 9910-D813,
9910-GS50GI
PUMPS 9910-VDR50 -D1064, -D1265 and D1516. Includes pressure gauge, 35 725
high pressure relief valve, complete by-pass lever, three
1/2" HB outlets with individual shut-offs & 1” HB by-pass.
Control unit for Models 9910-D503, -D813, -D1064, and
-D1265. Includes pressure gauge, high pressure relief
valve, complete by-pass lever,two 1/2" HB outlets with
individual shut-offs and 1” HB by-pass. For additional
ball valves, order 9910-130491.
9910-GS50GI
KIT NUMBER FOR PUMP MODEL DESCRIPTION

GEAR REDUCTION KITS
9910-KIT1640* 9910-D30, D303, D403 6:1 gear box for standard 5.5 hp gas
engien with 3/4" shaft.
9910-KIT1642 9910-D50, D503, 6:1 gear box for standard gas engine
D813, D1064, D1265 with 1" shaft.
*This kit can also be used with 9910-D50, D503 and D813, providing that pumps are operated at lower
pressures that do not exceed 5.5 hp gas engine capability. 9910-KIT1640
KIT NUMBER FOR PUMP MODEL DESCRIPTION
1-3/8” 6 SPLINE PTO SHAFT KITS

9910-KIT1704 9910-D50, D30, D303, D403 Female PTO coupler and
retaining clamp, torque arm
9910-KIT1708 9910-D50, D503, D813, D1064, D1265 and mounting bracket, chains
9910-KIT2204 9910-D503, D813, D1064, D1265 and necessary hardware.

KIT NUMBER FOR PUMP MODEL DESCRIPTION

1-3/8” 6 SPLINE PTO SHAFT KITS
9910-KIT1702 9910-D30 Male PTO shaft adapter, mounting
9910-KIT1706 9910-D50 bracket and necessary hardware.
9910-KIT1710 9910-D70, D115
9910-KIT2200 9910-D503, D303, D403
9910-KIT2201 9910-D813, D1064, D1265
