Page 365 - Catalog

www.bigwsales.com

NH3 Valves

Anhydrous Ammonia Splitters & Manifolds
The CDS-John Blue Precision Splitters should be used when
three, four or six CDS-John Blue Impellicones are used in parallel.

PART NO DESCRIPTION INLET OUTLET
SIZE SIZE
ANHYDROUS AMMONIA SPLITTERS & MANIFOLDS
IPS-3 3-Port Impellicone Splitter, 3 outlets 1-1/4"NPT 1" NPT
IPS-4 4-Port Impellicone Splitter, 4 outlets 1-1/4"NPT 1" NPT
NEW IPS-6 6-Port Impellicone Splitter, 6 outlets 1-1/4"NPT 1" NPT
NEW IPS-6
Flow Divider
Impellicone Flow Divider for Anhydrous Ammonia
• Accuracy: Evenly mixes the gas and liquid portions of NH3
and distributes accurately to each row.
• Simplicity: A simple design allows for ease of service without
removing the distribution lines, however it is recommended that
proper handling techniques \for NH3be used at all times.
•Variability: Handles all typical application rates without changing
any flow divider parts. NH3 & SAFETY PRODUCTS

PART NO DESCRIPTION INLET OUTLET
SIZE SIZE
IMPELLICONE FLOW METER
IP-1300 13 Outlet NH Flow Divider 1" NPT 1/4" NPT
3
IP-1800 18 Outlet NH Flow Divider 1" NPT 1/4" NPT IP-1800
3
IPS-3 Splitter 1-1/4" 1"

NH3 Valves

Designed specifically for anhydrous ammonia, the S8F33 is cost- NEW!
effective and built with quality materials to withstand the NH3
environment. Low torque design vented ammonia ball valve
Waterproof: Rated NEMA 6P Ignition safe: Rated NEMA 7D

PART NO SIZE CONTROL CYCLE TIME
S SERIES NH3 VENTED SS AMMONIA BALL VALVES
S8F33-10D20-P01 On/Off 0.8 sec.
S8F33-10D20-C01* On/Off 0.8 sec.
S8F22-20DW0-PF1 1" Regulating 3.0 sec.
S8F22-20DW0-CF1* Regulating 3.0 sec.
S8F22-20DU0-PF1 Regulating 8.0 sec.
S8F22-20DU0-CF1* Regulating 8.0 sec.
