Shutoff Valves and Spray Guns

Top quality hand valves for use with spray nozzles, extensions and handles to suit your
application needs. Hand valve assemblies may be made from parts shown on this
page. The “typical assembly” shown below includes 4727 handle, 4688 valve, 4673-8
curved extension with swivel body, TeeJet cap and flat spray tip.

Typical Shutoff Valve Assembly

AA31 for pressures Forged brass body and nickel-plated
up to 500 PSI (35 bar) steel trigger. Teflon® valve seat and
Comfortable palm fitting gun. For packing,stainless steel valve stem.
use with any TeeJet spray tip. 1/4" Weight 12 oz.(0.34 kg). Also supplied
NPS (M) inlet connection. as 31-1/4F with 1/4" NPT (F) inlet AA31
connection.

Valves

4688 Trigger Valve w/trigger 6104 Trigger Valve with SPRAY GUNS
lock. Max. flow rate 2 GPM trigger lock. Same as 4688
(7.6 l/min), max. pressure of except with 1/4" NPT (F)
250 PSI (17 bar). 1/4" NPT inlet and outlet connections.
(F) inlet connection, 11/16"– Brass material
16 (M) outlet connection. Use
with TeeJet and ConeJet® 6104
4688 tips, adjustable ConeJet tips
or MulteeJet® tips.
Brass material.

6466 Trigger Valve, same 6590 Trigger Valve, same
as 4688, less trigger lock, as 6104, less trigger lock,
with extra long trigger. with extra long trigger.
Brass material. Brass material.
6590
6466

Valve Handles
(Choice of valve handles—for above valves)
4727 Sure Grip Handle, brass,

Outlet connections are 1/4" NPT (M) 4727 rubber-covered, 1/4" NPS (M) hose
inlet connection.
to fit 1/4" NPT (F) inlets of all valves
shown. Choice of types for every need.
4754 Sure Grip Handle, brass,
rubber-covered, 3/4" garden hose
4754 thread (F) inlet connection.
