Page 322 - Catalog

ConeJet Adjustable Spray Tips

5500-PP 5500
The 5500 adjustable ConeJet tip is Knurled body of tip rotates through
also available in a polypropylene a half turn to provide spray selection
version. The polypropylene tip has from wide angle, finely atomized cone
the same performance spray to a straight stream spray. Tip
characteristics as the brass tip settings “A” and “B” represent two
and provides excellent chemi- extreme points of rotation in tip
cal resistance. O-Ring: EPDM is adjustment.
standard,Viton® is optional.

38720-PP
Provides adjustable spray from solid
stream to a hollow cone pattern.
Made of polypropylene material for
excellent chemical resistance. Fits
any 11/16"–16 TeeJet® male thread
bodies .30° offset from horizontal
SPRAY GUNS Extensions for Valves and Spray Guns
incorporated into main tip body.

22665 Extension Wand
CP22673-PP & CP22664-PP Adapters
For low volume and spot spraying applications.
Available in both 15"and 24" (38 cm and 61 cm)
adjustable ConeJet nozzles.
lengths, the extension fits on 25657-NYB adapter.
Maximum pressure 150 PSI (10 bar). Used for attaching standard TeeJet tips or CP22664-PP

22665

CP22673-PP
TriggerJet® Extension
22665-PP is for use with 22650-PP TriggerJet spray
gun. Maximum pressure rating of 150 PSI (10 bar).
Available in 15" and 24" (38 and 61 cm) lengths.
22665-PP
Straight and Curved Extensions
4673 and 6671—for pressures to 125 PSI (9 bar).
7715—for pressures to 250 PSI (17 bar). Fits models
23L and 31 GunJet® spray guns and trigger valves.

STRAIGHT CURVED CURVED EXTENSION
FIXED BODY SWIVEL BODY FIXED BODY LENGTH
EXTENSIONS 4673
7715-8 4673-8 6671-8 8" (203 mm)
7715-18 4673-18 6671-18 18" (457 mm)
7715-24 4673-24 6671-24 24" (610 mm)
7715-30 4673-30 6671-30 30" (762 mm)
7715-36 4673-36 6671-36 36" (914 mm) 7715
7715-48 4673-48 6671-48 48" (1,219 mm)
