Line Strainers
Mesh Size Color Guide:
MESH RIB Strainer heads are available in polypropylene, nylon,
SIZE COLOR aluminum and cast iron. Bowl materials include
SCREENS polypropylene or nylon. Each strainer includes
16 BRN/RED stainless steel screen (with polypropylene frames on
3/4" to 1-1/2" pipe sizes).
20 BEIGE
25/30 RED Maximum temperatures up to 38°C/100°F. Viton®
O-ring seal supplied with 3/4" and 1" Nylon models;
50/60 BLUE EPDM supplied with 3/4" and 1" polypropylene models;
80 YELLOW Buna-N gaskets supplied with 1-1/4" and 1-1/2" sizes.
100 GREEN Viton optional. CP16903 CP15941 CP14634
120 BRN
200 LT PINK STRAINER PIPE FLOW RATE W/5 PSI (0.34 PRESSURE SCREEN MESH
NUMBER CONN. BAR) PRESSURE DROP RATING SIZE*
LINE STRAINERS
CP15941-1-SSPP 16
AA124-1-1/4-AL-* 1-1/4" 60 (230) CP15941-2-SSPP 30
CP15941-3-SSPP 50
CP15941-4-SSPP 80
AA124-1-1/2-AL-* 1-1/2" 70 (260)
CP15941-5-SSPP 100
150 (10) CP15941-6-SSPP 120 LINE STRAINERS
AA124-2-AL-* 2" 160 (610) CP14634-1-SS 16
CP14634-2-SS 30
CP14634-3-SS 50
AA124-2-1/2-AL-* 2-1/2" 170 (640) CP14634-4-SS 80
AA124-AL CP14634-8-SS 100
STRAINER PIPE FLOW RATE W/5 PSI (0.34 PRESSURE SCREEN MESH
NUMBER CONN. BAR) PRESSURE DROP RATING SIZE*
LINE STRAINERS
CP16903-1-SSPP 16
AA124ML-3/4-AL-* 3/4" 23 (87) CP16903-2-SSPP 20
CP16903-3-SSPP 30
CP16903-4-SSPP 50
AA124ML-1-AL-* 1" 34 (129) CP16903-5-SSPP 80
CP16903-6-SSPP 100
CP16903-7-SSPP 200
AA124ML-1-1/4-AL-* 1-1/4" 60 (230) CP15941-1-SSPP 16
AA124ML-AL 150 (10) CP15941-2-SSPP 30
(with mounting holes) CP15941-3-SSPP 50
AA124ML-1-1/2-AL-* 1-1/2" 70 (260) CP15941-4-SSPP 80
CP15941-5-SSPP 100
How to order: CP15941-6-SSPP 120
Specify strainer number, AA124ML-2-AL-* 2" 160 (610) CP14634-1-SS 16
mesh size and material. CP14634-2-SS 30
Example: CP14634-3-SS 50
AA124-1-1/4-AL-50 AA124ML-2-1/2-AL-* 2-1/2" 170 (640) CP14634-4-SS 80
CP14634-8-SS 100
