Manifold Fittings

PART NO DESCRIPTION
PART NO DESCRIPTION
FLANGE x MALE NPT THREAD -316SS
M100MPTSS 1" Flange x 1" Male Thread BUTT WELD PIPE SWEEP
M200125MPTSS 2" Flange x 1-1/4" Male Thread BW220SWP90SS 2" 90º Full Port Stainless Steel Butt
M200150MPTSS 2" Flange x 1-1/2" Male Thread Weld Pipe Sweep
M200MPTSS 2" Flange x 2" Male Thread
M220150MPTSS 2" Full Port Flange x 1-1/2" MPT
M220MPTSS 2" Full Port Flange x 2" Male Thread PART NO DESCRIPTION
M300220MPTSS 3" Flange x 2" Full Port Male Thread
M300MPTSS 3" Flange x 3" Male Thread MANIFOLD BUTT WELD ADAPTER
M220BWASS 2" Full Port Stainless Steel Manifold
Butt Weld Adapter

PART NO DESCRIPTION
Rib keeps gasket in
FLANGED CROSS place during assembly.
M100CR 1" Flanged Cross
M200CR 2" Flanged Cross MANIFOLD SYSTEMS
M220CR 2" Full Port Flanged Cross PART NO DESCRIPTION
M220CRSS 2" Full Port SS Flanged Cross FLANGE GASKETS
M300CR 3" Flanged Cross
M100G 1" EPDM Manifold Gasket
M101G* 1" EPDM Manifold Gasket with Rib
M100GV 100 Series FKM (viton type) Gasket
150G 1-1/2" EPDM Gasket
PART NO DESCRIPTION 150GV 200 Series FKM (viton type) Gasket
200G 220 Series Full Port EPDM Gasket
FLANGE x HOSE BARB TEE 200GV 220 Series Full Port FKM viton Gasket
M100100HBT 1" Flange x 1" Hose Barb Tee M201G* 2" EPDM Manifold Gasket with Rib
M100125HBT 1" Flange x 1-1/4" Hose Barb Tee M221G* 2" Full Port EPDM Gasket with Rib
M220200HBT 2" Full Port Flange x 2" HB Tee 300G 3" EPDM Gasket
M300300HBT 3" Flange x 3" Hose Barb Tee 300GV 300 Series FKM (viton type) Gasket
M301G* 3" EPDM Manifold Gasket with Rib

PART NO DESCRIPTION
PART NO DESCRIPTION
FLANGE CLAMPS
FC100 100 Series Worm Screw Clamp UNIVERSAL FLANGED GASKETS
FC200 200 Series Worm Screw Clamp UFG0100E 1" EPDM Manifold Gasket
FC220 220 Series Worm Screw Clamp UFG0150E 1-1/2" EPDM Manifold Gasket
2" EPDM Manifold Gasket
UFG0200E
FC300 300 Series Worm Screw Clamp
UFG0300E 3" EPDM Manifold Gasket
