Manifold Fittings

PART NO DESCRIPTION
FLANGE x MALE QDC PART NO DESCRIPTION

M100A 1" Flange x 1" Male Adapter
M200A 2" Flange x 2" Male Adapter FLANGE x 45° HOSE BARB ELBOW
M220A 2" Full Port Flange x 2" Male Adapter M200150BRB45 2" Flange x 1-1/2" 45° HB Elbow
M300A 3" Full Port Flange x 3" Male Adapter

PART NO DESCRIPTION
PART NO DESCRIPTION
FLANGE x FEMALE NPT THREAD FLANGE x 90° HOSE BARB ELBOW
M100050FPT 1" Flange x 1/2" Pipe Thread M100075BRB90 1" Flange x 3/4" 90° HB Elbow
MANIFOLD SYSTEMS
M100BRB90 1" Flange x 1" 90° HB Elbow
M100075FPT 1" Flange x 3/4" Pipe Thread
M100FPT 1" Flange x 1" Pipe Thread M100125BRB90 1" Flange x 1-1/4" 90° HB Elbow
M200FPT 2" Flange x 2" Pipe Thread M100150BRB90 1" Flange x 1-1/2" 90° HB Elbow
M220FPT 2" Full Port Flange x 2" Pipe Thread M200100BRB90 2" Flange x 1" 90° Hose Barb Elbow
M300FPT 3" Flange x 3" Pipe Thread M200125BRB90 2" Flange x 1-1/4" 90° HB Elbow
M200150BRB90 2" Flange x 1-1/2" 90° HB Elbow
M200BRB90 2" Flange x 2" 90° Hose Barb Elbow
2" Full Port Flange x 1-1/2" 90° Hose
M220150BRB90
Barb Elbow
M220BRB90 2" Full Port Flange x 2" 90° HB Elbow
PART NO DESCRIPTION
M300220BRB90 3" Flange x 2" 90° Hose Barb Elbow
FLANGE x NPT THREAD M300BRB90 3" Flange x 3" 90° Hose Barb Elbow
M100075MPT 1" Flange x ¾" Male Thread
M100MPT 1" Flange x 1" Male Thread
M100125MPT 1" Flange x 1¼" Male Thread
M200125MPT 2" Flange x 1¼" Male Thread PART NO DESCRIPTION
M200150MPT 2" Flange x 1½" Male Thread
M200MPT 2" Flange x 2" Male Thread FLANGE x HOSE BARB
M220MPT 2" Full Port Flange x 2" Male Thread M100075BRB 1" Flange x 3/4" Hose Barb
M300MPT 3" Flange x 3" Male Thread M100BRB 1" Flange x 1" Hose Barb
M100125BRB 1" Flange x 1-1/4" Hose Barb
M200100BRB 2" Flange x 1" Hose Barb
M200125BRB 2" Flange x 1-1/4" Hose Barb
M200150BRB 2" Flange x 1-1/2" Hose Barb
PART NO DESCRIPTION M200BRB 2" Flange x 2" Hose Barb
M220100BRB 2" Full Port Flange x 1" Hose Barb
FLANGE x 45° HOSE BARB ELBOW M220125BRB 2" Full Port Flange x 1-1/4" Hose Barb
M100BRB45 1" Flange x 1" 45° Hose Barb Elbow M220150BRB 2" Full Port Flange x 1-1/2" Hose Barb
M200BRB45 2" Flange x 2" 45° Hose Barb Elbow M220BRB 2" Full Port Flange x 2" Hose Barb
M220BRB45 2" Full Port Flange x 2" 45° HB Elbow M300220BRB 3" Flange x 2" Hose Barb
M300BRB45 3" Flange x 3" 45° Hose Barb Elbow M300BRB 3" Flange x 3" Hose Barb
