Turbo TeeJet - Wide Angle Flat Spray Tips

CAPACITY 20"
PART PSI DROP CAPACITY ONE GPA GALLONS PER 1000 SQ. FT.
ONE
NUMBER SIZE NOZZLE NOZZLE 4 5 6 8 10 12 15 20 2 3 4 5
IN
IN GPM OZ/ MIN MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH
15 C 0.061 7.8 4.5 3.6 3.0 2.3 1.8 1.5 1.2 0.91 .021 .014 0.10 0.08 Features:
20 M 0.071 9.1 5.3 4.2 3.5 2.6 2.1 1.8 1.4 1.1 0.24 0.16 0.12 0.10 • Tapered edge wide angle flat spray
30 M 0.087 11 6.5 5.2 4.3 3.2 2.6 2.2 1.7 1.3 0.30 0.20 0.15 0.12
40 M 0.10 13 7.4 5.9 5.0 3.7 3.0 2.5 2.0 1.5 0.34 0.32 0.17 0.14 pattern for uniform coverage in
50 F 0.11 14 8.2 6.5 5.4 4.1 3.3 2.7 2.2 1.6 0.37 0.25 0.19 0.15 broadcast spraying.
60 F 0.12 15 8.9 7.1 5.9 4.5 3.6 3.0 2.4 1.8 0.41 0.27 0.20 0.16 • Large, rounded internal passage to
75 F 0.14 18 10.4 8.3 6.9 5.2 4.2 3.5 2.8 2.1 0.48 0.32 0.24 0.19 minimize clogging.
(100 MESH) TT11001 90 C F 0.092 19 11.1 8.9 7.4 5.6 4.5 3.7 3.0 2.2 0.51 0.34 0.26 0.20 • Excellent resistance to corrosive
0.15
4.6
3.4
12
6.8
0.31 0.21 0.16 0.13
1.4
5.5
1.8
15
2.7
2.3
20
0.44 0.29 0.22 0.18
0.13
3.9
9.7
M
7.7
17
3.2
30 C 0.11 14 8.2 6.5 5.4 4.1 3.3 2.7 2.2 1.6 0.37 0.25 0.19 0.15 solutions.
6.4
1.9
2.6
4.8
• Superior wear characteristics.
40 M 0.15 19 11.1 8.9 7.4 5.6 4.5 3.7 3.0 2.2 0.51 0.34 0.26 0.20
50 M 0.17 22 12.6 10.1 8.4 6.3 5.0 4.2 3.4 2.5 0.58 0.39 0.29 0.23 • Larger droplets for less
60 M 0.18 23 13.4 10.7 8.9 6.7 5.3 4.5 3.6 2.7 0.61 0.41 0.31 0.24 drift—15–90 PSI (1–6 bar).
75 F 0.21 27 15.6 12.5 10.4 7.8 6.2 5.2 4.2 3.1 0.71 0.48 0.36 0.29 • Automatic spray alignment with
TT110015 90 F 0.23 29 17.1 13.7 11.4 8.5 6.8 5.7 4.6 3.4 0.78 0.52 0.39 0.31 25612-*-NYR Quick TeeJet®
15 C 0.12 15 8.9 7.1 5.9 4.5 3.6 3.0 2.4 1.8 0.41 0.27 0.20 0.16
20 C 0.14 18 10.4 8.3 6.9 5.2 4.2 3.5 2.8 2.1 0.48 0.32 0.24 0.19 cap and gasket.
30 M 0.17 22 12.6 10.1 8.4 6.3 5.0 4.2 3.4 2.5 0.58 0.39 0.29 0.23 • Blockage-free passage means
40 M 0.20 26 14.9 11.9 9.9 7.4 5.9 5.0 4.0 3.0 0.68 0.45 0.34 0.27 less clogging.
50 M 0.22 28 16.3 13.1 10.9 8.2 6.5 5.4 4.4 3.3 0.75 0.50 0.37 0.30 • Unique internal configuration
60 M 0.24 31 17.8 14.3 11.9 8.9 7.1 5.9 4.8 3.6 0.82 0.54 0.41 0.33
75 M 0.27 35 20 16.0 13.4 10.0 8.0 6.7 5.3 4.0 0.92 0.61 0.46 0.37 means substantially longer wear life.
TT11002 90 F 0.30 38 22 17.8 14.9 11.1 8.9 7.4 5.9 4.5 1.0 0.68 0.51 0.41
15 VC 0.15 19 11.1 8.9 7.4 5.6 4.5 3.7 3.0 2.2 0.51 0.34 0.26 0.20
20 C 0.18 23 13.4 10.7 8.9 6.7 5.3 4.5 3.6 2.7 0.61 0.41 0.31 0.24
30 C 0.22 28 16.3 13.1 10.9 8.2 6.5 5.4 4.4 3.3 0.75 0.50 0.37 0.30 PUMPS
40 M 0.25 32 18.6 14.9 12.4 9.3 7.4 6.2 5.0 3.7 0.85 0.57 0.43 0.34
50 M 0.28 36 21 16.6 13.9 10.4 8.3 6.9 5.5 4.2 0.95 0.63 0.48 0.38
60 M 0.31 40 23 18.4 15.3 11.5 9.2 7.7 6.1 4.6 1.1 0.70 0.53 0.42
75 M 0.34 44 25 20 16.8 12.6 10.1 8.4 6.7 5.0 1.2 0.77 0.58 0.46 SPRAY TIPS & NOZZLES
TT110025 90 F 0.38 49 28 23 18.8 14.1 11.3 9.4 7.5 5.6 1.3 0.86 0.65 0.52
15 VC 0.18 23 13.4 10.7 8.9 6.7 5.3 4.5 3.6 2.7 0.61 0.41 0.31 0.24
20 VC 0.21 27 15.6 12.5 10.4 7.8 6.2 5.2 4.2 3.1 0.71 0.48 0.36 0.29
30 C 0.26 33 19.3 15.4 12.9 9.7 7.7 6.4 5.1 3.9 0.88 0.59 0.44 0.35
40 C 0.30 38 22 17.8 14.9 11.1 8.9 7.4 5.9 4.5 1.0 0.68 0.51 0.41
50 M 0.34 44 25 20 16.8 12.6 10.1 8.4 6.7 5.0 1.2 0.77 0.58 0.46
60 M 0.37 47 27 22 18.3 13.7 11.0 9.2 7.3 5.5 1.3 0.84 0.63 0.50
75 M 0.41 52 30 24 20 15.2 12.2 10.1 8.1 6.1 1.4 0.93 0.70 0.56
TT11003 90 M 0.45 58 33 27 22 16.7 13.4 11.1 8.9 6.7 1.5 1.0 0.77 0.61
15 XC 0.24 31 17.8 14.3 11.9 8.9 7.1 5.9 4.8 3.6 0.82 0.54 0.41 0.33
20 VC 0.28 36 21 16.6 13.9 10.4 8.3 6.9 5.5 4.2 0.95 0.63 0.48 0.38
30 C 0.35 45 26 21 17.3 13.0 10.4 8.7 6.9 5.2 1.2 0.79 0.60 0.48
30
24
19.8 14.9 11.9
0.40
51
1.4
40
9.9
7.9
0.91 0.68 0.54
5.9
C
(50 MESH) 50 C 0.45 58 33 27 22 16.7 13.4 11.1 8.9 6.7 1.5 1.0 0.77 0.61 TT11004-VP
36
18.2 14.6 12.1
29
24
9.7
C
7.3
1.7
0.83 0.67
1.1
0.49
63
60
90
30
17.8 14.9 11.9
22
1.4
1.0
77
M
2.0
0.60
45
36
0.82
8.9
TT11004 75 M 0.55 70 41 33 27 20 16.3 13.6 10.9 8.2 1.9 1.2 0.94 0.75 Spacing
15 XC 0.31 40 23 18.4 15.3 11.5 9.2 7.7 6.1 4.6 1.1 0.70 0.53 0.42
20 VC 0.35 45 26 21 17.3 13.0 10.4 8.7 6.9 5.2 1.2 0.79 0.60 0.48
30 VC 0.43 55 32 26 21 16.0 12.8 10.6 8.5 6.4 1.5 0.97 0.73 0.58 Spray
40 C 0.50 64 37 30 25 18.6 14.9 12.4 9.9 7.4 1.7 1.1 0.85 0.68 Height
50 C 0.56 72 42 33 28 21 16.6 13.9 11.1 8.3 1.9 1.3 0.95 0.76
60 C 0.61 78 45 36 30 23 18.1 15.1 12.1 9.1 2.1 1.4 1.0 0.83
75 C 0.68 87 50 40 34 25 20 16.8 13.5 10.1 2.3 1.5 1.2 0.92
TT11005 90 M 0.75 96 56 45 37 28 22 18.6 14.9 11.1 2.6 1.7 1.3 1.0
15 XC 0.37 47 27 22 18.3 13.7 11.0 9.2 7.3 5.5 1.3 0.84 0.63 0.50 Optimum Spray Height
20 XC 0.42 54 31 25 21 15.6 12.5 10.4 8.3 6.2 1.4 0.95 0.71 0.57
30 VC 0.52 67 39 31 26 19.3 15.4 12.9 10.3 7.7 1.8 1.2 0.88 0.71 20
40 C 0.60 77 45 36 30 22 17.8 14.9 11.9 8.9 2.0 1.4 1.0 0.82
50 C 0.67 86 50 40 33 25 19.9 16.6 13.3 9.9 2.3 1.5 1.1 0.91 110º 20"
60 C 0.73 93 54 43 36 27 22 18.1 14.5 10.8 2.5 1.7 1.2 0.99
75 C 0.82 105 61 49 41 30 24 20 16.2 12.2 2.8 1.9 1.4 1.1
TT11006 90 M 0.90 115 67 53 45 33 27 22 17.8 13.4 3.1 2.0 1.5 1.2 How to Order:
15 XC 0.49 63 36 29 24 18.2 14.6 12.1 9.7 7.3 1.7 1.1 0.83 0.67 Specify tip number.
20 XC 0.57 73 42 34 28 21 16.9 14.1 11.3 8.5 1.9 1.3 0.97 0.78
30 VC 0.69 88 51 41 34 26 20 17.1 13.7 10.2 2.3 1.6 1.2 0.94 Example:
40 VC 0.80 102 59 48 40 30 24 19.8 15.8 11.9 2.7 1.8 1.4 1.1 TT11001-VP –
50 C 0.89 114 66 53 44 33 26 22 17.6 13.2 3.0 2.0 1.5 1.2 Polymer w/VisiFlo® color-coding
60 C 0.98 125 73 58 49 36 29 24 19.4 14.6 3.3 2.2 1.7 1.3
75 C 1.10 141 82 65 54 41 33 27 22 16.3 3.7 2.5 1.9 1.5
TT11008 90 M 1.20 154 89 71 59 45 36 30 24 17.8 4.1 2.7 2.0 1.6
