Page 105 - Catalog

www.bigwsales.com

Manifold Pressure Spike Valves

Features:
• FKM (viton type) seals
• Precision molded in polypropylene.
• Preset pressure spring.
• Poppet is diamond turned, after molding, to make
it spherically perfect, which provides precise seal.
• 360° Orientation.

PART NO OUTLET FITTINGS

MANIFOLD PRESSURE SPIKE VALVES
MPRV100-050 1" Pressue Spike Valve
MPRV100-075 1" Pressue Spike Valve
MPRV100-100 1" Pressue Spike Valve
MPRV100-125 1" Pressue Spike Valve MPRV100-100
MPRV100-150 1" Pressue Spike Valve

Manifold Micro Valve

Manifold Micro Valve:
• 90° rotating handle.
• Standard FKM (viton type) seats and O-rings. MANIFOLD SYSTEMS
• Maximum operating pressure 300 P.S.I.

PART NO OUTLET FITTINGS

POLY MANIFOLD MICRO VALVES MLV100V
MLV100V 1" Manifold Micro Valve

Manifold Bolted Ball Valves 4 & 6 Bolt Valves

Features:
• FKM (viton type) seals
• Precision molded in polypropylene. MV300CF
• PTFE self-lubricating stem bushings
• Self-aligning ball moves freely against the
PTFE seats for smooth operation.
MV200CF
PART NO OUTLET FITTINGS

4 & 6 BOLT VALVES
MV100CF 1" Flange Ball Valve
MV200CF 2" Flange Ball Valve MV225CF
MV220CF 2" Full Port Flange Ball Valve
MV225CF 2" Full Port Flange 5 Way Valve
MV300 3" Standard Flange Ball Valve
MV300CF 3" Full Port Flange Ball Valve
