Page 315 - 2022 Online Catalog
P. 315
www.bigwsales.com
GunJet Spray Guns
For spot spraying, tree spraying, livestock spraying and power washing
at pressures from 30 to 800 PSI.
To operate spray gun, handle is rotated 360° from shutoff to maximum flow position. As handle is
turned, spray changes from initial cone spray through intermediate cone spray to straight stream.
Spray tips are interchangeable orifice discs made of corrosion- and erosion-resistant stainless steel.
PART ORIFICE PERFORMANCE LIQUID PRESSURE IN PSI SETTING “A” SETTING “C”
NUMBER DISC 100 PSI 800 PSI WIDE ANGLE STRAIGHT
NUMBER A C A C CONE SPRAY STREAM SPRAY
SPRAY GUNS
Capacity – GPM .53 .90 1.5 2.5
AY-SS Maximum Maximum
AA2-20 Max. Vert. Throw – ft. — 25 — 33
20 Horizontal Throw Horizontal Throw
Max. Horiz. Throw – ft. 6 35 8 42
Capacity – GPM .79 1.4 2.2 4.0 Choice of Materials and Capacities
AY-SS
AA2-30 Max. Vert. Throw – ft. — 27 — 3.4
30
Max. Horiz. Throw – ft. 7 38 9 45
Capacity – GPM 1.2 2.3 3.4 6.5
AY-SS
AA2-45 Max. Vert. Throw – ft. — 30 — 36 GunJet Number AA2
45
Max. Horiz. Throw – ft. 8 41 9 48 Overall length 24", weight 3-1/2 pounds, brass. 3/4" SPRAY GUNS
Capacity – GPM 1.6 3.6 4.5 10 garden hose thread (F) inlet connection. Also
AY-SS available in aluminum as GunJet AA2-AL, weight
AA2-60 Max. Vert. Throw – ft. — 32 — 40
60 1-1/4 pounds.
Max. Horiz. Throw – ft. 9 44 10 52
Capacity – GPM 2.3 4.9 6.7 14
AY-SS
AA2-90 Max. Vert. Throw – ft. — 35 — 44
90
Max. Horiz. Throw – ft. 10 47 12 57
Capacity – GPM 3.2 6.4 9.0 17 GunJet Number AA2A
AY-SS Overall length 15", weight 2-1/2 pounds, brass. 3/4"
AA2-120 Max. Vert. Throw – ft. — 37 — 48
120 garden hose thread (F) inlet connection. Also
Max. Horiz. Throw – ft. 11 49 13 62 available in aluminum as GunJet AA2A-AL,
Capacity – GPM 4.7 11 13 31 weight 1 pound. Same design as GunJet AA2
AY-SS
AA2-180 Max. Vert. Throw – ft. — 37 — 48
180
Max. Horiz. Throw – ft. 12 49 14 62 How to Order:
Capacity – GPM .36 .36 1.0 1.0 For complete gun, specify spray gun number and material.
AA143- D2 Max. Vert. Throw – ft. — 22 — 26 Example: AA2-20, Brass or AA2-AL20, Aluminum
AL-*-2
Max. Horiz. Throw – ft. 10 33 11 35 To order orifice disc only, specify orifice disc number.
Example: AY-SS 20
Capacity – GPM .82 .82 2.3 2.3
AA143-
AL-*-4 D4 Max. Vert. Throw – ft. — 27 — 32
Max. Horiz. Throw – ft. 10 36 11 40
Capacity – GPM 1.7 1.8 4.9 5.1
AA143- D6 Max. Vert. Throw – ft. — 33 — 38 GunJet Number AA143
AL-*-6 Overall length 22-1/4", weight 1-1/4 pounds and
Max. Horiz. Throw – ft. 10 46 11 54 only available in aluminum. Inlets are available
Capacity – GPM 2.8 3.3 8.1 9.4
AA143- with 3/4" or GH (Garden Hose) female threads.
AL-*-8 D8 Max. Vert. Throw – ft. — 35.5 — 42
Max. Horiz. Throw – ft. 10 54 11 60
Capacity – GPM 3.9 4.9 11.2 13.9 How to Order:
AA143- Examples: AA143-AL-3/4-6 AA143-AL-GH-6
AL-*-10 D10 Max. Vert. Throw – ft. — 37.5 — 44.5 To order orifice disc only, specify orifice disc number.
Max. Horiz. Throw – ft. 10.5 55 12 62 Example: D2
