Adapters and Accessories ChemSaver® Check Valves
QJ90-2-NYR In this type of nozzle body, the
• Fits standard Quick TeeJet bodies. diaphragm check valve is an integral
part of the nozzle assembly. This
• Made of Nylon with CP19438-EPR design eliminates the pressure drop A
gasket (included).
• Use with Quick TeeJet cap and associated with ball-type check valves.
gasket for automatic alignment The spring-backed diaphragm ensures B
when using flat fan spray tips. dependable closure. For maximum
operating pressures of 125 PSI (9 bar).
• 90° included angle between outlets.
When used with standard flat fan tips A-End Cap Subassembly
produces a twin type spray pattern for QJ90-2-NYR B- Valve Set C
improved coverage and canopy C-Strainer
penetration. D-Orifice Disc and Core D
PART NUMBER TO FIT 8355
QJ90-2-NYR Quick TeeJet Made of Nylon with Nylon/polypropylene
end cap assembly. Check valve opens
at 10 PSI (0.7 bar) pressure. Choice of
1/8" or 1/4" NPT (F) inlet connections.
Flow rate for 1/8" is 3 GPM at 5 PSI
22674-1/4-NYB pressure drop (11.4 l/min at 0.34 bar).
• Allows use of Quick Flow rate for 1/4" is 3.9 GPM at 5 PSI
TeeJet system with 1/4" pressure drop (15 l/min at 0.34 bar).
NPT female connections. 8355
22674-1/4-NYB PART NUMBER DESCRIPTION
8355-1/8-NYB Diaph. assembly, nylon BOOM COMPONENTS
PART NUMBER TO FIT 8355-1/4-NYB Diaph. assembly, nylon
22674-1/4-NYB 1/4" (M) thread
12328
Made of Nylon with Celcon®
QJ8355-NYB bonnet. Check valve opens at 7 PSI
• Allows use of Quick TeeJet (0.5 bar) pressure. (M) inlet con-
system with 1/8" and 1/4" NPT nection and (F) outlet connections.
female connections. Choice of 1/2" and 3/4" NPT sizes.
• Side mounting provides Flow rate for 1/2" is 12 GPM at 5 PSI
protection of the nozzle body. pressure drop (45 l/min at 0.34 bar).
• Features ChemSaver no-drip Flow rate for 3/4" is 16 GPM at 5 PSI
shutoff. Requires 10 PSI (0.7 bar) pressure drop (61 l/min at 0.34 bar). 12328-NYB
at the nozzle to open check valve.
• Standard diaphragm of EPDM QJ8355-NYB PART NUMBER DESCRIPTION
with optional Viton available upon 12328-1/2-NYB Diaph. check valve, nylon
request.
• Maximum operating pressure of 12328-3/4-NYB Diaph. check valve, nylon
300 PSI (20 bar).
• Flow rate: 2.25 GPM (8.5 l/min)
at 5 PSI (0.34 bar) pressure drop, 8360
3.18 GPM (12.0 l/min) at 10 PSI Made of Nylon with Nylon/
(0.69 bar) pressure drop. polypropylene end cap assembly.
Check valve opens at 10 PSI (0.7 bar)
pressure. 1/4" NPT (M) inlet connection.
Flow rate of 2.25 GPM at 5 PSI pres-
PART NUMBER TO FIT sure drop (8.5 l/min at 0.34 bar).
QJ8355-1/8-NYB 1/4" (F) 8360
QJ8355-1/4-NYB 1/4" (F)
PART NUMBER DESCRIPTION
8360- NYB Diaph. assembly, nylon
