Page 200 - Catalog

Centrifugal Pumps

MODEL DESCRIPTION MAX MAX MAX
NUMBER GPM PSI RPM
9300 SERIES CI & SS IMPELLER PEDESTAL-MOUNT MODELS NEW!
9308C- 2-piece shaft design with a 416 stainless steel wet end 900 58 16 GPM
PM15 and hardened 8620 drive end Life Guard® silicon
carbide seal, 5” SAE-flanged inlet x 4” SAE-flanged
outlet
9308C- 2-piece shaft design with a 416 stainless steel wet end 1078 72 18 GPM
GM25 and hardened 8620 drive endLife Guard® silicon
carbide seal, 5” SAE-flanged inlet x 4” SAE-flanged
outlet
9308C-PM15

MODEL DESCRIPTION MAX MAX MAX HYD.
PSI
GPM
GPM
NUMBER
PUMPS 9300 SERIES CI & SS HYDRAULIC SELF-PRIMING MODELS
13 GPM
9303C-
122
Open/closed center systems, Viton/ceramic seal,
130
HM1C-SP
NPT ports 1-1/2" inlet, 1-1/4" outlet
9303C-
HM2C-SP Open/closed center systems, Viton/ceramic seals, 104 80 6 GPM
NPT ports 1-1/2" inlet, 1-1/4" outlet
9303C- Open/closed center systems, Viton/ceramic seal, 120 95 24 GPM
HM3C-SP NPT ports 1-1/2" inlet, 1-1/4" outlet
9303C- Open/closed center systems, Viton/ceramic seal, 99 97 7 GPM
HM4C-SP NPT ports 1-1/2" inlet, 1-1/4" outlet
9303C- Open/closed center systems, NPT ports 1-1/2" inlet, 140 140 16 GPM
HM5C-SP 1-1/4" outlet
9303S- Open/closed center systems, Life Guard® silicon 114 130 13 GPM
HM1C-SP carbide seal, NPT ports 1-1/2" inlet, 1-1/4" outlet
9303S- Open/closed center systems, Life Guard® silicon 97 95 6 GPM
HM2C-SP carbide seal, NPT ports 1-1/2" inlet, 1-1/4" outlet
9303S- Open/closed center systems, Life Guard® silicon 125 98 20 GPM
HM3C-SP carbide seal, NPT ports 1-1/2" inlet, 1-1/4" outlet
9303S- Open/closed center systems, Life Guard® silicon 115 93 7 GPM 9303C-HM1C-SP
HM4C-SP carbide seal, NPT ports 1-1/2" inlet, 1-1/4" outlet
9303S- Open/closed center systems, Life Guard® silicon 147 145 16 GPM
HM5C-SP carbide seal, NPT ports 1-1/2" inlet, 1-1/4" outlet
9305C- Open/closed center systems, NPT ports 2" inlet, 2" 178 154 19 GPM
HM3C-SP outlet

Life Guard® silicon carbide seal - Add suffix “B” (i.e.: 9305C-HM3C-B-SP)

UPS Same Day Shipping!

198 Stockton, CA Fresno, CA Salinas, CA Yuma, AZ Stockton, CA Fresno, CA Salinas, CA Yuma, AZ
800-922-7253 800-532-0253 844-755-2410 800-752-2636 800-922-7253 800-532-0253 844-755-2410 800-752-2636
