Page 174 - Catalog

2" & 3" Gas Driven CI Centrifugal Pumps

Features:
• Stainless steel shaft sleeve to protect engine shaft.
• Carbon ceramic seal with stainless steel cup and spring
with FKM (viton type) rubber.
• Replaceable inlet and outlet flanges.
• Dynamically balanced impeller
• Self-priming

PART NO DESCRIPTION

2" & 3" CI PUMPS W/GAS ENGINES
2" Cast Iron Pump, 6.5 HP Briggs & Stratton®
200PI6PRO
Engine Pro Series
200PIH-5 2" Cast Iron Pump, 5.5 HP Honda® Engine
3" Cast Iron Pump, 9 HP Honda® Engine
300PIH-9
w/Electric Start 200PIH-5
3" Cast Iron Pump, 13 HP Honda® Engine
PUMPS 2" & 3" CI Pump Only & Bearing Pedestal Pumps
300PIH13
Electric Start

Features:
• Pump only packs complete and ready for attachment to
gasoline engine.
• Pedestal pump for long coupling to electric motor.
• Cast iron construction for rugged dependable service
• Replaceable inlet and outlet flanges
• Dynamically balanced impeller

PART NO DESCRIPTION

2" & 3" CI PUMP ONLY
200POI 2" Cast Iron Pump Only with 3/4" Straight Keyed Shaft
300POI 3" Cast Iron Pump Only for 1" Shaft 200POI

PART NO DESCRIPTION

2" & 3" CI BEARING PEDESTAL
200PBI 2" Cast Iron Bearing Pedestal with 3/4" Straight Shaft
300PBI 3" Cast Iron Bearing Pedestal w/1" Shaft

PART NO DESCRIPTION

2" & 3" CI C-FLANGE PUMPS
200POICF5/8 2" Cast Iron C-Flange Pump w/ 5⁄8" Shaft Sleeve
200POICF7/8 2" Cast Iron C-Flange Pump w/ 7⁄8" Shaft Sleeve 200PBI
300POICF* 3" Cast Iron C-Flange Pump w/11⁄8" Shaft Sleeve

172 Stockton, CA Fresno, CA Salinas, CA Yuma, AZ Stockton, CA Fresno, CA Salinas, CA Yuma, AZ
800-922-7253 800-532-0253 844-755-2410 800-752-2636 800-922-7253 800-532-0253 844-755-2410 800-752-2636
