Quick TeeJet Multiple Nozzle Bodies

QC360 Quick TeeJet® Nozzle Body with Cam Lever Coupling Adapter
• Same features as QJ360C multiple nozzle bodies.
• Body designed to fit into standard cam lever couplings allowing for PART NUMBER NUMBER OF
SPRAY
quick change to smaller capacity spray tips. OUTLETS
• Locating nib keeps body properly oriented in fitting.
• Flow Rate: 2.25 GPM (8.5 l/min) at 5 PSI (0.34 bar) pressure drop, QC363-NYB 3
3.18 GPM (12.0 l/min) at 10 PSI (0.69 bar) pressure drop. QC364-NYB 4
• 1.269 (32 mm) diameter tip body fits ¾" cam lever coupling. QC365-NYB 5

QC363 QC364 QC365

Quick TeeJet Multiple Nozzle Bodies

QJ360C Nozzle Body Series for Wet Booms
• Available with either 3, 4 or 5 spray positions
• Positive shutoff between each position. BOOM COMPONENTS
• Maximum operating pressure of 300 PSI (20 bar).
• Available in 20 mm, 25 mm, 1/2", 3/4" or 1" pipe connections.
• Includes ChemSaver® diaphragm check valve for drip-
free shutoff. Standard diaphragm opens at 10 PSI (0.7 bar).
• Standard EPDM diaphragm with Viton® available
as an option.
• Also available with optional 56720 Air ChemSaver or
55280 e-ChemSaver® shutoff valves.
• Flow Rate: 2.25 GPM (8.5 l/min) at 5 PSI (0.34 bar)
pressure drop, 3.18 GPM (12.0 l/min) w/10 PSI
(0.69 bar) pressure drop.
• Mounts to a 3/8" (9.5 mm) hole drilled in pipe or tubing.
• Molded hex socket in upper clamp for attaching to flat
surfaces. Accepts 5/16" or M8 bolt.

QJ363C QJ364C QJ365C

NUMBER NUMBER NUMBER
OF
OF
OF
PART NUMBER SPRAY TO CLAMP PART NUMBER SPRAY TO CLAMP PART NUMBER SPRAY TO CLAMP
ON
ON
ON
OUTLETS OUTLETS OUTLETS
QJ363C-1/2-NYB 3 1/2" Pipe QJ364C-1/2-NYB 4 1/2" Pipe QJ365C-1/2-NYB 5 1/2" Pipe
QJ363C-3/4-NYB 3 3/4" Pipe QJ364C-3/4-NYB 4 3/4" Pipe QJ365C-3/4-NYB 5 3/4" Pipe
QJ363C-1-NYB 3 1" Pipe QJ364C-1-NYB 4 1" Pipe QJ365C-1-NYB 5 1" Pipe
