Page 94 - Catalog

LEV Series Electric Push Lock Valves 1/4", 3/8", 1/2"

Features
• 12 Volt DC
• Stationary current draw: less than 0.04 amps.
• Rotating current draw: less than 0.40 amps.
• Stall current: 0.75 amps
• Response time: 1/3 sec open to close
• TFM seats
• EPDM seals
• Fiberglass reinforced polypropylene.
• Integrated mounting slot
• Standard 3 wire configuration.
• Max Pressure = 150 PSI @ 70 °F.

PART NO INLET
ELECTRIC VALVES LEV038PL 3/8" Full Port Electric Valve LEV050PL
LEV SERIES ELECTRIC PUSH LOCK VALVES
LEV025PL
1/4" Electric Valve

LEV050PL
1/2" Electric Valve

LEV Series Electric Push Lock Valves 1/4", 3/8"

Features LEV038PL
• 12 Volt DC With Spray Tip Adapter
• Stationary current draw: less than 0.04 amps.
• Rotating current draw: less than 0.40 amps.
• Stall current: 0.75 amps
• Response time: 1/3 sec open to close
• TFM seats
• EPDM seals
• Fiberglass reinforced polypropylene.
• Integrated mounting slot
• Standard 3 wire configuration.
• Max Pressure = 150 PSI @ 70 °F.

PART NO INLET

LEV SERIES ELECTRIC PUSH LOCK VALVES
LEV025PLST 1/4" Electric Valve
LEV038PLST 3/8" Full Port Electric Valve
LEV038PLST

92 Stockton, CA Fresno, CA Salinas, CA Yuma, AZ Stockton, CA Fresno, CA Salinas, CA Yuma, AZ
800-922-7253 800-532-0253 844-755-2410 800-752-2636 800-922-7253 800-532-0253 844-755-2410 800-752-2636
