Page 357 - Catalog

www.bigwsales.com

Hoses

All Purpose EPDM Rubber Hose

• Temperature Range: -40 to +200 ºF
• Applications: Widespread use in industrial, agricultural, construction, and marine
applications. Use also as a hot or cold water washdown, heavy-duty heater,
or low pressure agricultural spray hose.
• Construction: Cover is red or black abrasion and ozone-resistant EPDM with
spiral polyester yarn reinforcement. Silicone free core and cover.
• Available by the foot or in reels of 300 ft. for 1-1/4", 250 ft. for 1-1/2"
or 200 ft. for 2"
• Maximum pressure 200 P.S.I., 4 spiral.

How to Order:
L-81-R 1-1/4 (1-1/4" red hose)
L-81-R 1-1/2 (1-1/2" red hose)
L-81-R 2 (2" red hose)

All Purpose EPDM Rubber Hose

• Temperature Range: -40°F tp 180°F
• Applications: for liquid spray units, from hand-held units to large floater spray
units handling liquid fertilizer solutions. HOSES & CLAMPS
• Reinforcement: multiple high tensile textile spiral.
• Cover: red chemical, weather and ozone resistant EDPM.
• Available by the foot or in reels of 700 ft.
• Maximum pressure 150 P.S.I., 2 spiral.

How to Order:
L-85-R 3/8 (3/8" red hose)
L-85-R 1/2 (1/2" red hose)
L-85-R 3/4 (3/4" red hose)
L-85-R 1 (1" red hose)

Chemical Transfer Hose
• Temperature Range: -40°F – 180°F
• Applications: For chemical transfer of solvents and chemicals for in-plant or tank
truck use. Handles almost every common chemical in the chemical industry.
• Construction: Clear UHMWP (ultra-high molecular weight polyethylene)
• Reinforcement: Multiple high tensile textile braids with dual wire helix.
• Cover: green with white and orange stripe chemical, weather and ozone
resistant EPDM.
• Avaiable by the foot.

How to Order:
N-2700 3/4 (3/4" hose)
N-2700 1 (1" hose)
N-2700 1-1/4 (1-1/4" hose)
N-2700 1-1/2 (1-1/2" hose)
N-2700 2 (2" hose)
N-2700 3 (3" hose)
N-2700 4 (4" hose)
