TurfJet - Wide Angle Flat Fan Spray Nozzles

Features:
• Can be used with Quick TeeJet® cap QJ4676-*-NYR.
• Direct replacement for plastic hollow-cone, low-drift nozzles.
• Very large droplets, large orifice reduces clogging,
• Nozzle spacing—20–40" (50–100 cm).
• Spraying pressure—25–75 PSI (1.5–5 bar).

CAP 1 CAP 1 40" 20" QJ4676-90-1/4-NYR
PART PSI DROP NOZZLE NOZZLE • 90° fitting attaches to Quick TeeJet
NUMBER SIZE IN GPM IN GPA GALLONS PER 1000 SQ. FT.
OZ/MIN 4 5 6 8 10 12 15 20 2 3 4 5 bodies—1/4" female threaded
MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH MPH outlet.
25 UC 0.16 20 5.9 4.8 4.0 3.0 2.4 2.0 1.6 1.2 0.54 0.36 0.27 0.22 • Simple installation of TurfJet
30 UC 0.17 22 6.3 5.0 4.2 3.2 2.5 2.1 1.7 1.3 0.58 0.39 0.29 0.23 nozzles on vertical nozzle bodies.
1/4TTJ02 40 UC 0.20 26 7.4 5.9 5.0 3.7 3.0 2.5 2.0 1.5 0.68 0.45 0.34 0.27 • Nylon construction
50 XC 0.22 28 8.2 6.5 5.4 4.1 3.3 2.7 2.2 1.6 0.75 0.50 0.37 0.30
60 XC 0.24 31 8.9 7.1 5.9 4.5 3.6 3.0 2.4 1.8 0.82 0.54 0.41 0.33
75 XC 0.27 35 10.0 8.0 6.7 5.0 4.0 3.3 2.7 2.0 0.92 0.61 0.46 0.37 QJ4676-90-1/4-NYR PUMPS
25 UC 0.32 41 11.9 9.5 7.9 5.9 4.8 4.0 3.2 2.4 1.1 0.73 0.54 0.44
30 UC 0.35 45 13.0 10.4 8.7 6.5 5.2 4.3 3.5 2.6 1.2 0.79 0.60 0.48
1/4TTJ04 40 UC 0.40 51 14.9 11.9 9.9 7.4 5.9 5.0 4.0 3.0 1.4 0.91 0.68 0.54 SPRAY TIPS & NOZZLES
50 UC 0.45 58 16.7 13.4 11.1 8.4 6.7 5.6 4.5 3.3 1.5 1.0 0.77 0.61
(50 MESH) 75 UC 0.55 70 14.9 11.9 9.9 7.4 8.2 6.8 5.4 4.1 1.9 0.91 0.68 0.54 Spray Nozzle
0.49
UC
6.1
63
4.9
1.7
3.6
7.3
0.83 0.67
1.1
60
9.1
18.2 14.6 12.1
1.2
0.94 0.75
16.3 13.6 10.2
20
TurfJet
4.0
3.0
51
5.9
5.0
UC
25
1.4
0.40
30 UC 0.43 55 16.0 12.8 10.6 8.0 6.4 5.3 4.3 3.2 1.5 0.97 0.73 0.58
1/4TTJ05 40 UC 0.50 64 18.6 14.9 12.4 9.3 7.4 6.2 5.0 3.7 1.7 1.1 0.85 0.68
50 UC 0.56 72 21 16.6 13.9 10.4 8.3 6.9 5.5 4.2 1.9 1.3 0.95 0.76 1/4TTJ04-VS
60 UC 0.61 78 23 18.1 15.1 11.3 9.1 7.5 6.0 4.5 2.1 1.4 1.0 0.83
75 UC 0.68 87 25 20 16.8 12.6 10.1 8.4 6.7 5.0 2.3 1.5 1.2 .092
25 UC 0.47 60 17.4 14.0 11.6 8.7 7.0 5.8 4.7 3.5 1.6 1.1 0.80 0.64
30 UC 0.52 67 19.3 15.4 12.9 9.7 7.7 6.4 5.1 3.9 1.8 1.2 0.88 0.71 Spacing
1/4TTJ06 40 UC 0.60 77 22 17.8 14.9 11.1 8.9 7.4 5.9 4.5 2.0 1.4 1.0 0.82
Spray
50 UC 0.67 86 25 19.9 16.6 12.4 9.9 8.3 6.6 5.0 2.3 1.5 1.1 0.91 Height
60 UC 0.73 93 27 22 18.1 13.6 10.8 9.0 7.2 5.4 2.5 1.7 1.2 0.99
75 UC 0.82 105 30 24 20 15.2 12.2 10.1 8.1 6.1 2.8 1.9 1.4 1.1
25 UC 0.63 81 23 18.7 15.6 11.7 9.4 7.8 6.2 4.7 2.1 1.4 1.1 0.86
30 UC 0.69 88 26 20 17.1 12.8 10.2 8.5 6.8 5.1 2.3 1.6 1.2 0.94 Optimum Spray Height
40 UC 0.80 102 30 24 19.8 14.9 11.9 9.9 7.9 5.9 2.7 1.8 1.4 1.1 20
1/4TTJ08
50 UC 0.89 114 33 26 22 16.5 13.2 11.0 8.8 6.6 3.0 2.0 1.5 1.2
60 UC 0.98 125 36 29 24 18.2 14.6 12.1 9.7 7.3 3.3 2.2 1.7 1.3 20º 24"
75 UC 1.10 141 41 33 27 20 16.3 13.6 10.9 8.2 3.7 2.5 1.9 1.5 30º 30"
25 UC 0.79 101 29 23 19.6 14.7 11.7 9.8 7.8 5.9 2.7 1.8 1.3 1.1
30 UC 0.87 111 32 26 22 16.1 12.9 10.8 8.6 6.5 3.0 2.0 1.5 1.2 40º 39"
40 UC 1.00 128 37 30 25 18.6 14.9 12.4 9.9 7.4 3.4 2.3 1.7 1.4
1/4TTJ10
50 UC 1.12 143 42 33 28 21 16.6 13.9 11.1 8.3 3.8 2.5 1.9 1.5
60 UC 1.22 156 45 36 30 23 18.1 15.1 12.1 9.1 4.1 2.8 2.1 1.7 How to Order:
75 UC 1.37 175 51 41 34 25 20 17.0 13.6 10.2 4.7 3.1 2.3 1.9 Specify tip number.
25 UC 1.19 152 44 35 29 22 17.7 14.7 11.8 8.8 4.0 2.7 2.0 1.6 Examples:
30 UC 1.30 166 48 39 32 24 19.3 16.1 12.9 9.7 4.4 2.9 2.2 1.8 1/4TTJ04-VS – Stainless Steel
40 UC 1.50 192 56 45 37 28 22 18.6 14.9 11.1 5.1 3.4 2.6 2.0
1/4TTJ15 w/VisiFlo® color-coding
50 UC 1.68 215 62 50 42 31 25 21 16.6 12.5 5.7 3.8 2.9 2.3
60 UC 1.84 236 68 55 46 34 27 23 18.2 13.7 6.3 4.2 3.1 2.5 1/4TTJ06-VP – Polymer with
75 UC 2.05 262 76 61 51 38 30 25 20 15.2 7.0 4.6 3.5 2.8 VisiFlo color-coding
